The Valgro LBF Karma Series can be used for plasma and laser cut flat parts for various applications such as deburring, edge rounding. Valgro Karma series is available in various configurations including Belt + Brush, Belt + Disc, Belt + Brush + Disc,
VALGRO long belt finishing machines have a flexible abrasive belt which enables finishing on flat surfaces of big dimensions. VALGRO-LBF machine is ideal for Hot and Cold rolled plasma cut parts deburring and grinding.
-
Overview
Valgro Samarth Series Deburring & Finishing machine provides a uniform roughening brush effect for batter powder coating. This machine is highly productive than a conventional deburring system, can eliminate manual deburring work. Valgro has developed various models for sheet Deburring in configuration of flexibility and lower operating costs. The burr can vary when punching or laser cutting your materials. Burrs created via laser cutting and punching adhere to the material in various strengths. Therefore, finding a comprehensive deburring solution is crucial.
-
Features
Features
- Deburring and edge rounding of parts up to 50 mm material thickness
- Save up to 60% operational and labour costs
- Removal of spots on the sheet metal surface
- Processing front sides of the parts
- Edge rounding of interior and exterior contours at one time
- Dry eco-friendly operations
- Can be individually adjusted or turned on and off electrically.
- Maximum productivity while maintaining machining quality
- Guarantees optimum tool utilization over the entire working width.
- Faster and simpler tool change within just a few minutes
- Modular and compact in modern machine design - smaller footprint
- Improved work environment - Reduction of dust, dirt, and noise
Advantages compared to the manual treatment
- Significantly higher productivity combined with superior part quality
- Consistent quality over the entire production run, versus scratches and divots produced by manual side grinders
- Avoid Unhealthy operation, Compared to the operation with a side grinder your employees
- Do not have to suffer under flying sparks, dust, dirt, or noise
- No physical strain for your employees caused by vibration or unhealthy posture
-
Technicality
Model KARAM LBF32-BR LBF32-BRR LBF32-BDD LBF50-BRR LBF50-BDD Head Type Belt / Roller / Disc B + R B + R + R B + D + D B + R + R B + D + D Work Surface Top Side Top Side Top Side Top Side Top Side Process: Wet / Dry Dry Dry Dry Dry Dry Work head 2 3 3 3 3 Application Deburring + Edge Rounding Deburring + Edge Rounding Deburring + Edge Rounding Deburring + Edge Rounding Deburring + Edge Rounding Finish Achieved - - - - - Burr Qualification Class 1,2,3 Class 1,2,3 Class 1,2,3 Class 1,2,3 Class 1,2,3 Type of Material Carbon steel Carbon steel Carbon steel Carbon steel Carbon steel Min. Max Width 50-800 50-800 50-800 50-1250 50-1250 Min. Length 100 100 100 100 100 Min. Max Thickness 3-100 3-100 3-100 3-100 3-100 Weight of capacity 100kg 100kg 100kg 200kg 200kg Abrasive Belt width 125 125 125 125 125 Abrasive Belt Size - - - - - Roller Brush Diameter 225 225 - 225 - Disc Brush Diameter - - 200 - 200 Brush Action R = Rotate O = Oscillate R + O R + O R + O R + O R + O Conveyor Type R= Roller / B = Belt Belt Belt Belt Belt Belt Conveyor speed MPM Min / Max 0.5 - 10 0.5 - 10 0.5 - 10 0.5 - 10 0.5 - 10 Dust Extraction Model No DCS-3 DCS-3 DCS-3 DCS-5 DCS-5 Electrical parameters The integrated frequency converter allows the machine to work worldwide with all power supply systems and enables smooth start and enhanced motor protection. -
Applicatons
- Panel builder
- Sheet metal fabricator
- Automobiles
- Railways
- Instrumentation
- Laser cut shop
-
